Global sections
Sometimes, initializing variables of a formula can require a large amount of calculations. Since you
would normally initialize variables in the init section of a
fractal formula
 or a
coloring algorithm
 (or
the transform section of a
transformation
), these calculations are performed again and again for
every pixel.
Often, they only depend on parameter settings, and therefore the results are the same for every
pixel. To avoid doing many repeated calculations, you can move them to the global section. This is a
special section at the start of a formula that is executed once per image.
Use the global section to perform per image calculations and store the results in variables that can
be read in other sections. Variables declared here are treated as read only in other sections, so you
cannot use this to share variables across pixels (that would not work reliable).
In the following example, the global section is used to pre calculate an array of random values that
is the same for every pixel. These random values are subsequently used to disturb a standard
Mandelbrot set.
MandelbrotModified {
global:
  float
values[
#maxiter
]

int
i =
0

int
seed =
12345678

while
i
100

seed =
random
(seed)
    values[i] = seed /
#randomrange

i = i +
1

endwhile
init:

z = (
0
,
0
)

int
iter =
0
; "i" is already taken
loop:

z =
sqr
(z) +
#pixel
+ values[iter]
  iter = iter +
1
bailout:

|z|
4
}
Notes
G
Global sections are often combined with
arrays
 to compute look up tables that can speed up
the formula tremendously.
G
You can even declare an array equal to the size of the image (with the
#width
 and
#height
predefined symbols) and calculate the entire fractal in the global section of a coloring
algorithm. The final section is then used only to return colors or index values from this
array. This enables you to implement fractal types like IFS and flame fractals that are not
natively supported by Ultra Fractal. This technique does have some limitations: it can require
a fair amount of memory and the progress of the calculation is not reported. It is very slow
and memory intensive with
rendering to disk
, especially with
anti aliasing
, and it does not
289
