Tomcat i7230A S5160

                                                                  Chapter 3: BIOS Setup

Reset Configuration Data

If you install a new piece of hardware or modify your computer s hardware configuration, the

BIOS will automatically detect the changes and reconfigure the ESCD (Extended System

Configuration Data). Therefore, there is usually no need to manually force the BIOS to

reconfigure the ESCD.

However, sometimes, the BIOS may not be able to detect the hardware changes. A serious

resource conflict may occur and the operating system may not even boot as a result. This is

where the Reset Configuration Data BIOS feature comes in.

This BIOS feature allows you to manually force the BIOS to clear the previously saved ESCD

data and reconfigure the settings. All you need to do is enable this BIOS feature and then

reboot your computer. The new ESCD should resolve the conflict and allow the operating

system to load normally.

Please note that the BIOS will automatically reset it to the default setting of No after

reconfiguring the new ESCD. So, there is no need for you to manually disable this feature after

rebooting.

Yes / No

Large Disk Access Mode

This option determines whether a hard drive with more than 1024 cylinders, more than 16

heads and or more than 64 tracks per sector is present on the system. Set this option to DOS

if such a hard drive is present. Else, set this option to Other.

Virtually, all modern hard disks have these characters so leave this option at DOS, unless you

know otherwise.

DOS / Other

Route Port 80h cycles to

This feature allows you to route Port 80h I/O cycles to LPC or PCI bus.

LPC / PCI

Legacy USB Support

When enabled, the BIOS takes control of the USB ports. Enable this only if you run an OS that

does not support USB (e.g. DOS) or when you have USB hardware like USB mice that you

want to use even before the operating system loads.

Enabled / Disabled
