Tomcat i7230A S5160

                                                                 Chapter 1: Introduction

1.2   Hardware Specifications

Processor

Integrated LAN Controllers

Single LGA775 socket

Two Broadcom  BCM5721 LAN

Supports Intel

  Prescott / Smithfield /

controllers

Cedar Mill  processor

PCIe x1 interface

1066/800/533MHz FSB

1000/100/10Mb/s speed

Chipset

Intelligent Platform Management

Intel  Mukilteo  E7230 MCH + ICH7R  Interface

chipset

Renesas H8S2167/2168 Baseboard

Support for 1066MHz (1.066GHz) FSB

Management Controller (BMC)

SMSC SCH5017 Super I/O chip

Tailored for IPMI 2.0 specification

Supports remote Power on/off and

Memory

reset support (IPMI over LAN)

Four 240 pin DDR2 DIMM sockets

Server Management Daughter card

Supports ECC/non ECC DIMMs

via built in 2x25 header

Maximum of 8GB Unbuffered DDR2

533/667

BIOS

PhoenixBIOS  on 8Mbit Flash ROM

Expansion Slots

Support APM 1.2, ACPI 1.0b

One (1) PCI Express x16 slot (w/ x8

Serial Console Redirect

signal) from Mukilteo MCH

PXE via Ethernet, USB device boot

One (1) PCI Express x16 slot (w/ x4

PnP, DMI 2.0, WfM 2.0 Power

signal) from ICH7R

Management

Four (4) PCI 32 bit, 33MHz slots

User configurable H/W monitoring

Watchdog timer (from Super I/O)

Integrated I/O

Multiple boot options

One 9 pin 16550 UART serial port

48 bit LBA support

One ECP/EPP/SPP parallel port (via

Power management: S0, S1, S3,

header)

S4, S5

One 15 pin VGA port

Eight (8) USB 2.0 ports (four at rear,  Form Factor

three headers via cable, one internal

ATX (12  x 9.6 , 305mm x 244mm)

vertical USB connector)

EPS12V/SSI (24 + 8pin) power

PS/2 mouse and keyboard connectors

connectors

Standard/integrated SATA connectors

Stacked PS/2 keyboard and mouse

Two RJ 45 10/100/1000 LAN ports

connectors

USB 2.0 (four) rear connectors

System Management

Serial (one) and VGA (one)

CPU thermal & voltage monitor support

connectors

4 pin fan monitoring header w/ PWM

Two RJ 45 LAN connectors with

LEDs

Integrated SATA 2.0 Controller

Four SATA2.0 ports from Intel ICH7R

Regulatory

Integrated Host RAID 0,1 support

FCC Class B (DoC)

European Community CE (DoC)

Integrated Video Controller

XGI XG20 PCI Controller

16MB DDR memory

2

http://www.tyan.com
