Chapter 8      Command Reference

Privilege Level 15 Commands

Syntax Description

proto Name of protocol. Enter snmp, snmp trap, ip, icmp, tcp, or udp to specify

the protocol for which you want to view the packet content. You must specify

either a protocol or a port.

port Use the port number to specify the protocol to observe, instead of specifying

the protocol name. You must specify either a protocol or a port.

port The port number.

interface eth[0 5] The interface to observe. On the HSE, eth0 corresponds to the

port labeled A on the back panel, and eth1 corresponds to the port labeled B.

host, host2 The host(s) to observe.

host The host name(s).

Usage Guidelines

You can either specify a protocol by name or specify a port; you must specify one

or the other. Optionally, you can specify the interface and specify one or two hosts

to observe.

The command allows you to continuously observe the packets. Enter Ctrl C to

terminate the command.

Examples

The following command listens displays the SNMP packets in the interface:

dumptcp proto snmp interface eth0

The following command listens to packets from port 161 only with abc.com as

either the source or destination host:

dumptcp port 161 host abc.com

erase config

To erase the configuration in Flash memory and reload the device, use the erase

config command:

erase config

Syntax Description

This command has no arguments or keywords.
