Chapter 5      Configuring Devices

CSS VIP Redundancy

It must not match the IP address of any redundant interfaces.

It must not match the IP address of any interface on any other node on the

subnet.

Related Topics

CSS VIP Redundancy, page 5 84

Creating a Virtual Router, page 5 84

Updating CSS VIP Redundancy Objects, page 5 91

Creating Virtual Interface Redundancy, page 5 88

Creating Critical Services, page 5 89

Creating Virtual Interface Redundancy

Use this option to create virtual interfaces. The VR must already be established.

Procedure

Step 1

Select Configure > CSS VIP Redundancy.

Step 2

From the TOC, click Virtual Interface Redundancy.

Step 3

Click Add to select two redundant devices from the lists available. Click Next.

Step 4

Select the virtual router. If no VR appears, you must configure your device using

the ip virtual router command. The VR can be created in HSE or see the CSS

Redundancy Configuration Guide at http://www.cisco.com/en/US/partner

/products/hw/contnetw/ps792/products_configuration_guide_book09186a00801

ee05c.html. Click Next.

Note

The VR ID must match on two CSS devices. For example, if there are VRs

on both devices but no two have common VR IDs, then no VR will be

shown in HSE.

Step 5

Enter the Virtual Interface IP address, then click Next.
