Chapter 5      Configuring Devices

Grouping Real Services by Physical Servers

Step 9

To rename a service chassis, select Rename. Enter the new name, then click OK.

Related Topics

Activating Server Load Balancing Services, page 5 45

Configuring Server Load Balancing Services, page 5 48

Entering Device Credentials, page 4 3

Grouping Real Services by Physical Servers, page 5 77

Creating a Service Chassis, page 5 80

Deleting a Service Chassis, page 5 83

Viewing a Service Chassis

This feature allows you to view a service chassis and the services related to it.

Note

Your login determines whether you can use this option.

Procedure

Step 1

Select Configure  > Service Chassis. The service chassis' display in the left

pane.

Step 2

To see the services that are grouped to a service chassis, click on the plus sign (+)

next to the service chassis name or IP address. The IP addresses display below the

chassis name or IP address. click on the plus sign (+) next to the IP address to see

the real services.

Step 3

If you want to see the relationships of the services that use the service chassis,

then select the service in the tree.

Selecting the real services shows the reverse configuration in the right pane. The

selected real service is displayed in white and any virtual service that is affected

is displayed in red.

User Guide for the CiscoWorks Hosting Solution Engine 1.8.1

5 82

OL 6319 01
