Chapter 5      Configuring Devices

Configuring Server Load Balancing Services

Deleting a Device Pair

You can delete device association from a device pair when you no longer want the

redundancy coverage.

Procedure

Step 1

In the configuration tree, click on a device or module IP address and click Delete.

Step 2

Click OK in the confirmation window to delete the device.

When redundancy associations are deleted from a device pair, the CSM 3.xor later

device module or CSS device shows as not available in the Configure tab.

Related Topics

Understanding Redundancy Support, page 4 41

Expected Behaviors for Redundant Devices, page 4 42

Showing Device Status

You can access server status information on CSM 2.x and 3.x or later modules,

CSS, and LocalDirector devices using the Status button. Use this feature to check

if there are any active connections before suspending a device from service.

Procedure

Step 1

Select Configure  > Configuration.

Step 2

Click on the plus sign (+) next to the device name or IP address to expand the tree.

Step 3

Select the check box next to the service for which you want status, then click

Status. You may need to expand the server folder in order to select your server.

Depending on the device, the following may display:

Number of active connections for real or virtual servers

State of the selected real or virtual server

User Guide for the CiscoWorks Hosting Solution Engine 1.8.1

OL 6319 01

5 75
