Chapter 5      Configuring Devices

Configuring Server Load Balancing Services

If you delete a content rule, a warning that you will delete service bindings or

a confirmation window appears.

If you delete a service, a warning appears containing which content rules and

owners are going to be unbound.

Step 2

Click Delete. Click OK.

A confirmation or an error message window may display depending on the

outcome of the deletion task.

Creating LocalDirector Real or Virtual Servers

For the LocalDirector devices, a virtual server presents a single IP address that

represents a group of real servers. Service requests to the virtual server are load

balanced among the real servers. Real servers are actual host servers with unique

IP addresses that provide TCP/IP services to the network. The virtual server IP

address is published to your network community, but the real server IP addresses

can remain unpublished, so that you can hide actual site implementation details

and provide single points of contact for users.

Note

Your login determines whether you can use this option.

Procedure

Step 1

Click on the device name or IP address to select the properties form.

Step 2

Select Create Virtual Server or Create Real Server. The selected window

appears.

Step 3

If you are creating a virtual server, the Create Virtual window appears. Enter the

field information, then click Continue.

If you are creating a real server, the Create Real Server window appears. Enter the

field information, then click Continue.

The task is done and a confirmation window appears.

Step 4

Click OK to update the configuration tree and return to the properties window.

An error message window appears if there are errors.
