Chapter 5      Configuring Devices

Viewing Provisioned Devices

Field Description

NAT

The client type of network address

translation (NAT). However, the NAT

client pool must already be defined.

There is only one entry per NAT client

per server farm.

NAT Client Pool

The name used to identify the client

address pool.

Backup

The entry indicates whether there is a

sticky connection backup. (This will

not appear for CSM 3.x or later

versions.)

Step 2

Click to expand the server farm name and list its associated

CSM Real Servers,

page 5 25

 and

Redirect Virtual Servers, page 5 26

.

CSM 3.x or Later Real Servers

Expanding Real Servers provides a list of all real servers. The associated server

farm name appears in parentheses.

Procedure

Click the real servers to view their properties. A properties table with the

following fields appears in the right pane:

Field Description

Address

The server IP address.

DNS Name

The DNS name of the device.

Port

The server port number.

State

The operational state of the server.

User Guide for the CiscoWorks Hosting Solution Engine 1.8.1

OL 6319 01

5 33
