Chapter 5      Configuring Devices

Viewing Provisioned Devices

Field Description

Minimum Connections

The threshold value for the minimum

number of active connections that the

real server is assigned. (This will not

appear for CSM 3.x or later versions.)

Redirect Virtual Server

The virtual servers dedicated to real

servers.

This mapping provides connection

persistence for clients to real servers

across TCP sessions. (This will not

appear for CSM 3.x or later versions.)

Step 2

To place the real server in standby mode, click InService Standby. Standby mode

allows all current connections and sessions on the server to continue, but prevents

new sessions from starting. Once all traffic on the server ends, you can gracefully

suspend the server without interrupting current user sessions. To end standby

mode, suspend or activate the server.

Redirect Virtual Servers

Redirect virtual servers will appear for CSM 2.x and previous versions.

Procedure

Step 1

Click on the redirect virtual servers to view their properties. A properties table

with the following fields appears in the right pane:

Field Description

Name

The name of the server.

Address

The IP address of the server.

Protocol

The server protocol.

Port

The port number.
