Chapter 5      Configuring Devices

Viewing Provisioned Devices

SSL Proxy Server

Field

Description

Number

The index of the SSL server in the SSL

proxy list.

VIP Address

Virtual IP address. This should match a

VIP in content rule.

Port

Virtual TCP port number of the SSL

server.

SSL Version

The module version number for the

SSL.

RSA Key

The name of an RSA key pair.

RSA Certificate

The name of an RSA certificate for

authentication and packet encryption

DSA Key

The name of a Diffie Hellman (DSA)

key pair.

DSA Certificate

The name of a DSA certificate used in

the exchange of digital signatures.

DH Param

Name of a Diffie Hellman key

exchange parameter file association.

CSS Show SSL Statistics

The following output is displayed for CSS Show SSL Statistics:

SSL Acceleration Statistics

Component:SSL Proxy Server Slot:3

Count Description

1200 Handshake started for incoming SSL connections

1180 Handshake completed for incoming SSL connections

   0 Handshake started for outgoing SSL connections

   0 Handshake completed for outgoing SSL connections

   2 Active SSL flows high water mark

   9 Current number of TCP Proxy flows

  30 Maximum number of TCP Proxy flows
