Chapter 4      Managing Devices

Device Redundancy Configuration Examples

Step 16

Select Configure  > Configuration to complete your provisioning tasks (such as

creating owners, services, or content rules).

Related Topics

Activating Server Load Balancing Services, page 5 45

Configuring Server Load Balancing Services, page 5 48

Creating a CSS Owner, page 5 53

Creating a CSS Service, page 5 54

Creating a Content Rule, page 5 55

Grouping Real Services by Physical Servers, page 5 77

CSM Configuration Example

This example explains how to add two redundant CSM 3.x modules to the Hosting

Solution Engine. For detailed instructions, see

Managing Device Redundancy,

page 4 37

.

In previous Hosting Solution Engine versions, the XML interface could be

enabled from HSE. This is no longer supported in the current version. You must

configure the XML interface on the CSM.

You must also have redundancy configured between the two CSMs. For

additional information, refer to the CSM 3.1 documentation on Cisco.com.

In this example, the devices each contain a CSM 3.x module. The devices

community string and credentials are the same on both devices.

Procedure

Step 1

Select Devices >Device Management > Device Manager, then click Add to add

your seed devices.

Step 2

Select the device type and enter an IP address in the IP address text box. Then

click Next.

Devices must be entered one at a time. XML must be configured on the device.
