Chapter 4      Managing Devices

Device Management

Task

Procedure

3. Verify connectivity

From the Administration tab, select Diagnostics, then Connectivity.Type

from the Hosting

the device name or IP address and click Ping.

Solution Engine to the

devices you want to

manage.

4. Set community

Use the LocalDirector CLI to set the community strings. For example,

strings.

snmp server community public

5. Enable Telnet.

Use the LD CLI to enable Telnet. For example,

telnet

Note

The SNMP Server Host must be configured on the LocalDirector

devices.

6. (Optional) Set the

On LocalDirector devices, enter configuration mode and use the following

system name, contact,

commands.

and location variables.

To set the system name, use the hostname name command. For

example, set hostname HSE LD 1

.

To set the system contact, use the snmp contact contact command.

To set the location, use the snmp location location command.

7. (Optional) Configure  Add device names and IP addresses into the DNS server. See your DNS

DNS server.

server documentation for instructions.

User Guide for the CiscoWorks Hosting Solution Engine 1.8.1

OL 6319 01

4 19
