3 Making your first recording

3) Play the tape for about 10 seconds and then stop the tape.

4) Press the counter reset button.

3.3

Setting the level

The aim of this section is to teach you to set the input level so that

the average signals coming from the microphone will light the

0

meter indicator, and the loudest will light the

+6

 indicator.

1) Make sure all

OUTPUT LEVEL

 controls are set to

0

. Put on

the headphones and set the

PHONES LEVEL

 to the

0

 position.

If you do not do turn down the speaker volume, you will probably get

feedback ( howlround ) when you start using the microphone.

2) Set both

TRIM

 controls to the

LINE

 position.

Although you will probably end up with this control at the

MIC

 posi

tion, or close to it, for now, set it to

LINE

.

3) Take the

INPUT 2

 fader to the

 0

 mark. Bring the

INPUT 1

fader up to between the

7

 and

 8

 marks.

This is called the  nominal  position, and is the position where the

electronics controlled by the fader will not have to amplify the signal

too much (causing noise) or have too much signal going into them

(causing distortion).

4) Switch the microphone on if necessary. Speak into the

microphone at the volume you will be recording.

It is important than when you perform these level checks that you

speak, sing or play at the level at which you will actually be recording.

Most people, when they first start recording, tend to be a little louder

than when they are simply checking the levels.

5) While talking into the microphone, turn the

INPUT 1 TRIM

control clockwise until the left

0

 indicator is lit most of the

time, and the

+6

 indicator is lit on the loudest parts.

If the

0

 indicator hardly lights at all, you may be too far from the

microphone, or you are speaking too softly. If the microphone uses

batteries, you may need to replace them.

You can also bring the fader up from the

 7 8

 position to increase the

level, but you should do this only after the

TRIM

 control has been

turned fully clockwise.

6) Adjust the

PHONES LEVEL

 until you are comfortable with

what you hear in the headphones.
