Mandelbrot

The Mandelbrot set is the most well known fractal type. Although it is

calculated by a simple formula, it is incredibly complex. As you zoom in,

more and more ever changing detail becomes visible, such as little

"baby" Mandelbrot sets and all kinds of spirals.

Because the Mandelbrot set lends itself well to basic zooming and

exploring, it is a good starting point if you are new to fractals.

The formula provides the following parameters:

For the standard Mandelbrot set, this should be set to (0, 0). Other values

create distorted shapes that can be interesting, but they are usually not as

Starting point

well formed as the standard set. Try (0,  0.6), for example.

Specifies the exponent. The default value is (2, 0), resulting in the classic

equation.

z = z

2

 + c

Power

Try (3, 0) and (4, 0) and so on to increase the number of main "buds". Non

integer values for the real part of the exponent will interpolate between these

well formed sets. If the imaginary part is not zero, the fractal will be further

distorted.

Specifies the magnitude of z that will cause the formula to stop iterating. To

obtain the "true" Mandelbrot set, this should be set to 4 or larger. Larger

values tend to smooth the outside areas.

Bailout value

With the

Basic

 coloring algorithm and the

Color Density

 set to 4, try the bail

out values 4 and then 16 to see the difference.

Some coloring algorithms require specific bail out values for good results.

Notes

G

The Mandelbrot set is also available as a more efficient built in formula with fewer options.

See

Mandelbrot (Built in)

.

G

The Mandelbrot set also acts as a map of

Julia sets

. Use

Switch mode

 to switch to related

Julia sets.

See Also

The Mandelbrot set

Standard formulas

152
