3.6.5

The depth Keyword

The depth keyword is also used in combination with the content keyword to spec

ify an upper limit to the pattern matching. Using the depth keyword, you can specify an

offset from the start of the data part. Data after that offset is not searched for pattern

matching. If you use both offset and depth keywords with the content keyword, you can

specify the range of data within which pattern matching should be done. The following

rule tries to find the word  HTTP  between characters 4 and 40 of the data part of the

TCP packet.

alert tcp 192.168.1.0/24 any  > any any (content: \

   "HTTP"; offset: 4; depth: 40; msg: "HTTP matched";)

This keyword is very important since you can use it to limit searching inside the

packet. For example, information about HTTP GET requests is found in the start of the

packet. There is no need to search the entire packet for such strings. Since many packets

you capture are very long in size, it wastes a lot of time to search for these strings in  the

entire packet. The same is true for many other Snort signatures.

3.6.6

The content list Keyword

The content list keyword is used with a file name. The file name, which is used as

an argument to this keyword, is a text file that contains a list of strings to be searched

inside a packet. Each string is located on a separate line of the file. For example, a file

named  porn  may contain the following three lines:

 porn

 hardcore

 under 18

The following rule will search these strings in the data portion of all packets

matching the rule criteria.

alert ip any any  > 192.168.1.0/24 any (content list: \

   "porn"; msg: "Porn word matched";)

You can also use the negation sign ! with the file name if you want to generate an

alert for a packet where no strings match.

3.6.7

The dsize Keyword

The dsize keyword is used to find the length of the data part of a packet. Many

attacks use buffer overflow vulnerabilities by sending large size packets. Using this key

word, you can find out if a packet contains data of a length larger than, smaller than, or
