Snapshot table function

Information returned

SNAPSHOT_DYN_SQL

Point in time statement information from the SQL

statement cache for the database.

Similar to snapshot commands, the amount of information returned from table

snapshots functions is controlled by the monitor switches. Because snapshots

can collect large amounts of diagnostic data, enabling all monitor switches

(especially DYNAMIC SQL) can have a very negative impact on database

performance.

All the monitoring utilities use memory heap, controlled by the

MON_HEAP_SZ

database manager parameter. This monitoring heap size should be increased

when many applications access snapshot data.

Event monitoring

Event monitors are used to monitor the performance of DB2 over a fixed period

of time. The information that can be captured by an event monitor is similar to the

snapshots, but event monitors examine transition events in the database, and

consider each event as an object. Event monitors can capture information about

DB2 events in the following areas:

Database

: An event of database information is recorded when the last

application disconnects from the database.

Tables

: All active table events will be recorded when the last application

disconnects from the database. An active table is one which has been altered

or created since the database was activated. The monitor captures the

number of rows read and written to the table.

Deadlocks

: A deadlock event is recorded immediately when a deadlock

occurs. This monitor also has an additional option

WITH DETAILS

. This option

will capture additional information, like which SQL statement was being

executed when the deadlock occurred, and what locks were held by the

application that encountered the deadlock. The information captured by the

monitor focuses on the locks involved in the deadlock and the applications

that own them.

Buffer pools

: A buffer pool event is recorded when the last application

disconnects from the database. The information captured contains the type

and volume of use of the buffer pool, use of pre fetchers and page cleaners,

and whether or not direct I/O was used.

Table spaces

: A table space event is recorded when the last application

disconnects from the database. This monitor captures the same information

as the buffer pool monitor, but the information is summarized at a table space

level.
