NOTE 2: You must license GFI WebMonitor for the number of
computers that will connect to the ISA Server for Access Control and
monitoring. If you will be installing on multiple ISA Servers you will
need a license for each installation.
NOTE 3: Entering the license key should not be confused with the
process of registering your company details on our website. This is
important, since it allows us to give you support and notify you of
important product news. Register on:
http://www.gfi.com/pages/regfrm.htm
Advanced GFI WebMonitor deployments
The installation and usage of GFI WebMonitor always follows the
same paths and procedures. Install GFI WebMonitor, open Internet
Explorer and access the configuration and monitoring interface
through the following URL:
http://monitor.isa
. The ISA Server which
picks up the request will respond.
In the case of multiple routed ISA Server installations you need to
manually edit a file so that the various GFI WebMonitor download
windows will not interfere with each other. This is achieved by
overwriting the default
http://monitor.isa
 URL with a dedicated
real/virtual IP which will clearly identify GFI WebMonitor making the
request as well as identify which download window is to process the
reply.
Deploying and using GFI WebMonitor on multiple ISA
Servers or ISA Server arrays
1. Install GFI WebMonitor on each of the ISA Server computers that
you want to monitor.
2. On each GFI WebMonitor deployment use Notepad (or an HTML
editor) to open the DownloadingPage.html file located in GFI
WebMonitor installation directory. Change the address contained in
the following variables to a real/virtual IP address that is routable via
the ISA Server on which you are making the change. E.g.,
http://130.168.0.1:

   ThisISAServerAddress  variable which is set by default to
http://monitor.isa.

   SecondISAServerAddress  variable containing an IP address
which is set by default to http://1.1.1.1. This variable must contain
the same value that has been specified for the
 ThisISAServerAddress  variable.
NOTE: Assign IP addresses to both of the above mentioned variables
in order to avoid configuration problems.
3. After you have completed all the required changes, restart all ISA
Servers where GFI WebMonitor is installed (i.e., the ISA Servers
where the changes to the DownloadingPage.html have been made).
4. To open GFI WebMonitor interface page of a particular ISA Server,
you must call it by the address specified in the relative
 ThisISAServerAddress  or  SecondISAServerAddress  variables
(e.g.,  http://130.168.0.1).
GFI WebMonitor 3
Installing GFI WebMonitor

 11
