Chapter 5      Configuring Devices

Grouping Real Services by Physical Servers

Editing a Service Chassis, page 5 81

Deleting a Service Chassis, page 5 83

Creating a Service Chassis

To group real services by common physical servers into something called a

service chassis do the following.

Note

Your login determines whether you can use this option.

Procedure

Step 1

Select Configure  > Service Chassis. The service chassis (IP addresses or chassis

names) display in the left pane.

Step 2

To create a service chassis, click Edit. The Edit Service Chassis window appears.

Step 3

Select Add. The Edit Service Chassis Configuration window appears.

Step 4

Enter the service chassis name, then click Add. The Edit Service Chassis

Configuration window appears.

Step 5

To move an IP address into the new service chassis group, select the service

chassis from the lower half of the window and click Select. Then select the IP

address from the IP column and click the up arrow.

Step 6

If you are adding more than one IP address or name to a service chassis, click

Apply. This saves your changes and allows you to continue working in the Edit

Service Chassis Configuration window.

If you have finished your service chassis configuration, click OK. A confirmation

window appears, click OK. This applies your changes and closes the window.

Related Topics

Activating Server Load Balancing Services, page 5 45

Configuring Server Load Balancing Services, page 5 48

Entering Device Credentials, page 4 3

User Guide for the CiscoWorks Hosting Solution Engine 1.8.1

5 80

OL 6319 01
