Chapter 5      Configuring Devices

Grouping Real Services by Physical Servers

Binding LocalDirector Services

On LocalDirector devices, you can associate one or more real servers with a

virtual server.

Procedure

Step 1

Click on the LocalDirector virtual server IP address to select the properties form.

Step 2

To bind real servers to a virtual server, select Real Server Binding. The Real

Server Bindings window appears.

Step 3

Move the IP address of the server you want to add to the Bound Real Servers

column from the Available Real Servers column using the arrow keys, then click

Save.

Step 4

Click OK to update the configuration tree and return to the properties window.

An error message window appears if there are errors.

Related Topics

Entering Device Credentials, page 4 3

Activating Server Load Balancing Services, page 5 45

Configuring Server Load Balancing Services, page 5 48

LocalDirector, page 5 18

LocalDirector Virtual Servers, page 5 19

LocalDirector Real Servers, page 5 20

Understanding the Configuration Tree Layout, page 5 3

Grouping Real Services by Physical Servers

Use the Service Chassis tab to allow you to group real services by common

physical servers into something called a service chassis. After creating a service

chassis, you can suspend or activate all the real services belonging to that service

chassis together so that the web server can be shutdown or brought up safely.

User Guide for the CiscoWorks Hosting Solution Engine 1.8.1

OL 6319 01

5 77
