Chapter 5      Configuring Devices

Viewing Provisioned Devices

Table 5 1

Show SSL Statistics (continued)

Field

Description

Bad macs received

Total number of SSL records received with an

incorrect MAC.

Pad errors

Number of occurrence of wrong padding

bytes in SSL record.

Step 3

Expand the Proxy Services folder and select a proxy server to display the server

properties.

Field Description

Name

Name of the service.

Server IP

The IP address of the target server for

the proxy.

Server Port

The port number of the target server for

the proxy.

Trustpoint

Defines the CA server, the key

parameters, key generation methods,

and the certificate enrollment methods

for the proxy server.

Virtual IP

The virtual server IP address for which

the SSL Services Module is the proxy.

Virtual Port

The virtual serve port number for

which the SSL Services Module is the

proxy.

State

Operational and administrative state.

Step 4

Click Show SSL Statistics on the properties form to display SSL related

statistics. An example of the output appears below.

Show Service Statistics   test

conns attempted     : 0             conns completed     : 0

full handshakes     : 0             resumed handshakes  : 0

conns in handshake  : 0             conns in data       : 0

renegs attempted    : 0             conns in reneg      : 0

blocks encrypted    : 0             bytes encrypted     : 0
