Chapter 5      Configuring Devices

Viewing Provisioned Devices

Field Description

Predictor

The load balancing algorithm for

selecting a real server in the server

farm.

NAT

The client type of network address

translation (NAT). However, the NAT

pool must already be defined.

There can be one NAT server entry and

one NAT client entry.

NAT Client Pool

The name used to identify the client

address pool.

Step 2

Click the plus sign (+) to expand the server farm name and list its associated

IOS

SLB Server Farms, page 5 37

.

Step 3

Click the Real Server DNS name or IP address to view its properties. See

IOS

SLB Real Servers, page 5 38

 for properties table fields.

IOS SLB Real Servers

Expanding the Real Servers provides a list of all real servers. The associated

server farm name appears in parentheses.

Procedure

Click the real server names to view their properties. A properties table with the

following fields appears in the right pane:

Field Description

Address

The IP address of the real server.

DNS Name

The DNS name of the device.

Port

The server port number.

State

The operational state of the server.
