Chapter 5      Configuring Devices

Viewing Provisioned Devices

Field Description

Weight

The weighting value for the virtual

server predictor algorithm. Higher

values indicate higher availability for

the server to do work.

Maximum Connections

The threshold value for the maximum

number of active connections that the

real server is assigned.

If the maximum number of

connections is reached, IOS SLB

automatically switches all further

connection requests to another server

until the connection number drops

below the specified limit.

Minimum Connections

The threshold value for the minimum

number of active connections that the

real server is assigned. (This will not

appear for CSM 3.x or later versions.)

Redirect Virtual Server

The virtual servers dedicated to real

servers.

This mapping provides connection

persistence for clients to real servers

across TCP sessions. (This will not

appear for CSM 3.x or later versions.)

CSM 3.x or Later Probes

Configuring probes to the real servers allows you to determine if the real servers

are operating correctly.

Field

Description

Probe Name

The name of the configured probe.

Probe Type

Type of probe for including

HTTP

,

ICMP

, Telnet,

TCP

,

FTP

,

SMTP

, and

DNS

.

1
