Chapter 5      Configuring Devices

Viewing Provisioned Devices

Field Description

Service

The server load balancing special

service, such as FTP.

Server Farm

The name of the server farm with

which this server is associated.

State

The operational state of the server.

Idle Timer

The idle timeout interval in seconds.

Sticky Group

A number identifying the sticky group

to which the virtual server belongs.

Sticky Timer

The sticky timeout interval in seconds.

Sticky Network Mask

The sticky subnet mask number. Client

sessions whose source IP addresses fall

within the netmask are directed to the

same real server.

Parse Length

The maximum number of bytes to

parse.

Webhost Relocation

A string to be sent in response to HTTP

requests to the host name. Only the

beginning of the relocation string is

specified. The remaining portion is

taken from the original HTTP request.

Webhost Backup

The relocation string sent in response

to HTTP requests in the event that the

redirect server is out of service. Only

the beginning of the relocation string is

specified. The remaining portion is

taken from the original HTTP request.

SSL Port

The SSL port number or HTTPS,

which is Secure Hypertext Transfer

Protocol.

Step 2

Expanding the redirect virtual servers lists any associated clients.

Step 3

To view the client properties, click on a client name. A properties table with the

following fields appears:

User Guide for the CiscoWorks Hosting Solution Engine 1.8.1

OL 6319 01

5 27
