Chapter 5      Configuring Devices

Provisioning Overview

LocalDirector devices containing virtual servers and real servers.

Catalyst 6000 Series devices with IOS SLB containing virtual servers,

clients, server farms and real servers.

Catalyst 6000 Series devices with CSM 2.x and 1.x modules with server

farms, real servers, virtual servers, redirect virtual servers, and clients.

Catalyst 6000 Series devices with multiple CSM 3.x (or later) modules each

of which can have probes, server farms, real servers, virtual servers, and

clients.

For additional information on supported devices, see the Supported Devices Table

document on your Recovery disk or Cisco.com.

Related Topics

Activating Server Load Balancing Services, page 5 45

Configuring Server Load Balancing Services, page 5 48

Grouping Real Services by Physical Servers, page 5 77

Understanding the Configuration Tree Layout, page 5 3

Device Name Display in Configure Tab

This topic discusses how the Configure tab displays each supported device in the

configuration tree.

If reverse DNS lookup is enabled on the HSE and the device name is configured

on the DNS server, the DNS name is displayed in this field. If the DNS name is

not available, the sysname SNMP variable is displayed instead. If neither the DNS

name nor the sysname is available, the device IP address is displayed. Therefore,

the order of preference is:

DNS name

IP address

This affects the Views, Reports, User Accounts, and Administration tabs. The

Configure tab options have some exceptions to this rule.

For CSS redundant devices, the device specific pair icon appears next to the

device pair name you entered into the device credentials form. Hosting Solution

Engine appends the type of device and the pair designation after that; such as

CSS_bldg_X(css pair).
