Device Redundancy Configuration Examples

The CSS management interface IP is not routable, so at least one HSE interface

needs to be in the same subnet in order to manage the redundant CSS pair.

In this example, the device community string and credentials are the same on both

devices.

Procedure

Step 1

Select Devices >Device Management > Device Manager, then click Add to add

your seed devices.

Step 2

Select the CSS device type and enter two management interface IP addresses in

the IP address text box. Then click Next. The SNMP Community Strings dialog

box appears.

Tip

The CSS management interface is not routable, so the Hosting Solution Engine

must be on the same subnet as the CSS management interface. If you are not sure

about how to determine the management interface of the CSS device, see the CSS

documentation on Cisco.com.

Step 3

Enter the SNMP community string information for these devices. If they are not

the same, you must enter the devices into the Add form one at a time. Click Next.

The Set Credentials dialog box appears.

Step 4

Enter the user and password credential information. Then click Next.

Select the HTTPS option to curb network traffic. HSE checks to ensure this device

is running HTTPS.

Step 5

To validate device credentials, select the check box, then click Next or Finish. If

you do not select to validate, the device is added but you may be unable to use the

other features that require credentials.

Step 6

To add device summary information as displayed, click Finish.

If the seed devices were added successfully, the Device Manager window appears

and the devices will appear with Undiscovered status. If the seed devices were not

added, an error message appears. Check to be sure the device type is correct and

that the device is reachable from the Hosting Solution Engine. See

Setting Up

Your Network, page 4 10

 for details on setting up your CSS.

Step 7

Select Devices >Device Management > Device Redundancy. Click Add. The

CSS Devices window appears.
