Chapter 4      Managing Devices

Device Management

Setting Up Content Switching Modules (CSM 3.x or Later)

For CSM modules, configure the following:

Task

Procedure

1. Set up the VLAN for  In order to set up the XML interface from the HSE, you need to define at

the XML interface.

least one VLAN on the CSM with an IP address routable from HSE. For

additional information, refer to the appropriate CSM documentation on

Cisco.com.

2. Configure

See  Configuring Connection Redundancy  in the Catalyst 6000 Family

redundancy between

Content Switching Module Installation and Configuration Note, Release 3.x

two CSMs.

or later.

3. Enable and configure  In order to keep track of service state transitions, use the snmp server

SNMP traps to be sent

command to enable and configure SNMP traps on the CSM. For example, on

to the Hosting Solution  the Catalyst 6500 MSFC:

Engine.

snmp server community public RO

snmp server enable traps slb real virtual csrp

snmp server host 192.168.65.11 public

In this example, the HSE IP is 192.168.65.11 and the SNMP community

string is public.
