Chapter 4      Managing Devices

Device Management

Setting Up Catalyst 6000 Series Devices

For Catalyst 6000 Series devices, configure the following. If your Catalyst 6000

device has a Content Switching Module (CSM), see

Setting Up Content Switching

Modules (CSM 3.x or Later), page 4 17

 for more configuration tasks. If your

Catalyst 6000 device has an SSL Services Modules, see

Setting Up Secure Socket

Layer (SSL) Services Modules, page 4 18

 for more configuration tasks.

Task

Procedure

1. Upgrade your

Visit the Software Center at Cisco.com for software downloads.

network device

software to the

supported versions.

2. Verify connectivity

From the Administration tab, select Diagnostics, then Connectivity.Type

from the Hosting

the device name or IP address and click Ping.

Solution Engine to the

devices you want to

manage.

3. Enable SNMP.

Use the IOS device CLI to enable the SNMP server. For example,

snmp server community public ro

4. Enable Telnet.

Use the IOS device CLI to enable Telnet. For example,

telnet

Note

The SNMP Server Host must be configured on the device.

5. (Optional) Set the

On the IOS devices, enter configuration mode and use the following

system name, contact,

commands.

and location variables.

To set the system name, use the hostname name command. For

example, set hostname HSE R1.

To set the system contact, use the snmp contact contact command.

To set the location, use the snmp location location command.

6. (Optional) Configure  Add device names and IP addresses into the DNS server. See your DNS

DNS server.

server documentation for instructions.

User Guide for the CiscoWorks Hosting Solution Engine 1.8.1

4 16

OL 6319 01
