Chapter 4      Managing Devices

Device Management

Device credentials are required if you plan to use many of the tools on the Hosting

Solution Engine.

Adding Seed Devices

You can manually add the following devices using Device Manager:

Adding a CSS, page 4 6

Adding a CSM, page 4 7

Adding a Generic Device, page 4 8

 (includes LocalDirector and PIX Firewall

devices)

Adding a CSS

Procedure

Step 1

Select Devices >Device Management > Device Manager.

Note

Devices must support IP and SNMP connectivity.

Step 2

Click Add.

The Add Devices dialog box appears.

Step 3

Select the CSS device type and enter the IP address for each device in the IP

address field.

The device IP addresses must appear on separate lines.

Step 4

Click Next. The SNMP Community Strings dialog box appears.

Step 5

Enter the device community strings and click Next. See

Modifying Multiple

Device SNMP Settings, page 4 29

 for variable descriptions.

Step 6

The Set Credentials dialog box appears. Enter the device credential information

and click Next. For details on this dialog box, see

Entering Device Credentials,

page 4 3

.

Step 7

The Validate Credentials pane displays. Select the check box if you want HSE to

validate device credentials. Click Next.

Step 8

The Add Device Summary pane displays. Click Finish.

If an error occurred, reenter the information into the dialog boxes again.
