Chapter 5: Diagnostics
5.1   Hardware Monitor Information
ICH5 SMBus base address = EC80h
Winbond83782D hardware Monitor Information
Hardware Monitor Chip 1:
             Winbond83782D
Slave Address:
             0x29h
Chip Clock:
             14.318MHz
Sensor Name
Bank
Register        Other
CPU1 Fan
    0
0x28h
     controlled by PWM1
CPU2 Fan
    0
0x29h
     controlled by PWM3
Chassis Fan 3
    0
0x2Ah
     controlled by PWM4
System Volt 3.3V
    0           0x22h
System Volt 5V
    0
0x23h
System Volt 12V
    0
0x24h
     R1 = 28K, R2 = 10K
Battery Voltage
    5
0x51h
System(VRM) temp     0
0x27h
     2N3904 diode
CPU1 533FSB temp    1          0x50h           PII compatible diode
CPU2 533FSB temp    2          0x50h           PII compatible diode
W83627HF Super IO hardware Monitor Information
Hardware Monitor Chip 2:
             WinbondW83627HF (Super IO)
Slave Address:
             0x2ah
Chip Clock:
             48.000MHz
Sensor Name
Bank
Register
Chassis Fan 4
0
0x28h
Chassis Fan 5
0
0x29h
Chassis Fan 6
0
0x2Ah
73
              http://www.TYAN.com
