C M P   2 . 0

Tag Name

Description

Required

list cache max  This specifies the number of read lists that can be tracked by  No, default is

this entity. This option is discussed in Chapter 6 of the

1000

JBossCMP Documentation.

table name

This is the name of the table that will hold data for this

No, default is

entity. Each entity instance will be stored in one row of this

ejb name

table.

In the cmp field element, you can control the name and datatype of the column. A cmp field

can also be mapped to several columns, and this is discussed in Chapter 3 of the JBossCMP

Documentation.  A detailed description of each element is shown in Table 9 2.

Table 9 2, cmp field Tags

Tag Name

Description

Required

field name

This is the name of the cmp field that is being configured. It  Yes

must match the name of a cmp field declared for this entity

in the ejb jar.xml file.

column name

This is the name of the column to which the cmp field is

No, default is

mapped.

field name

not null

If this empty element is present, JBossCMP will add NOT

No, default for

NULL to the end of the column declaration when

primary key

automatically creating the table for this entity.

fields and

primitives is

not null

jdbc type

This is the JDBC type that is used when setting parameters in  Only required if

a JDBC PreparedStatement or loading data from a JDBC

sql type is

ResultSet. The valid types are defined in java.sql.Types.

specified, default

is based on

datasource

mapping

sql type

This is the SQL type that is used in create table statements

Only required if

for this field. Valid sql types are only limited by your

jdbc type is

database vendor.

specified, default

is based on

datasource

mapping

87
